Name: ABA Plastic Film Extrusion Machine
Brand: CHAOXIN
SKU: 00068
Rating: 4.1 (84 reviews)

Product Specifications

Model		CX-ABA-700	CX-ABA-900	CX-ABA-1100
Suitable material		LDPE,HDPE,LLDPE	LDPE,HDPE,LLDPE	LDPE,HDPE,LLDPE
Film width		200-600mm	400-800mm	400-1000mm
Flim thickness		0.005-0.10mm	0.005-0.10mm	0.005-0.10mm
Output	HD	65kg/h	85kg/h	110kg/h
Output	LD	75kg/h	95kg/h	120kg/h
Extrusion unit
Screw diameter		Φ45*2	Φ50*2	Φ55*2
Screw L/D		30:1 \| 32:1 High speed screw	30:1 \| 32:1 High speed screw	30:1 \| 32:1 High speed screw
Screw material		Double alloy material	Double alloy material	Double alloy material
Barrel material		Double alloy material	Double alloy material	Double alloy material
Barrel cooling fan		550W*6	550W*6	550W*6
Main motor		11kw*2	15kw*2	18.5kw*2
Barrel temperature control		3 ZONE*2	3 ZONE*2	3 ZONE*2
Average power consume		28kw	35kw	45kw
Die head	HD	60/80mm	80mm	100mm
Die head	LD	120mm	150mm	250mm
Temperature control		ZONE 12	ZONE 12	ZONE 12
Air ring		Double vent air ring	Double vent air ring	Double vent air ring
Air blower		4kw	5.5kw	7.5kw
Roller width		700mm	900mm	1100mm
Effective width		600mm	800mm	1000mm
Take-up speed		10-120m/min	10-120m/min	10-120m/min
Take-up motor		1.5kw	1.5kw	2.2kw
Winding type		Surface friction winding	Surface friction winding	Surface friction winding
Winding speed		10-120m/min	10-120m/min	10-120m/min
Voltage		380V,50HZ,3PHASE	380V,50HZ,3PHASE	380V,50HZ,3PHASE
Machine weight		3T	3.5T	4T
Machine size (LWH)		635.2m	63.55.8m	646.2m

Comparision

WHY CHOOSE US?

CATEGORY

Chaoxin

Others

1. Screws

⭐⭐⭐

Optimized screw raises the extrusion volume and using lifespan. Higher anti-corrupt and anti-grind ability.

Customized screw keyway and 30:1 or 32:1 L/D double alloy screws with vacuum fire treatment.

Only 28:1 or 30:1 L/D single alloy screw

2. Motor

⭐⭐⭐⭐

The motor operates with frequency conversion, which shows its advantages in terms of energy saving.

Imported from American GE or Germany SIEMENS (with a three-year warranty)

Other brands from China domestic market (with only one year warranty)

3. Up-traction

⭐⭐⭐⭐

The up-traction determines the Traction stability, plastic film flatness and embossing effect.

5-rollers traction, one embossing roller, one bending roller, one polyurethane roller and two traction rollers.

Three rollers or four rollers traction with normal rubber.

4. Frame

⭐⭐

The thick frame makes the machine more durable and reliable.

The square tubes of machines are all thickened with a diameter of 120mm.

The mainstream in the market is 80mm in diameter

5. Gear Box

⭐⭐⭐

External circulation oil cooling system and hard tooth ensures the high working speed and lifespan of the gear joint.

Xiaoshan brand hard tooth oil-cooled type, with filter, circulating oil and external cooling pump.

Soft tooth gear box Other brands of from China domestic market without external oil cooling system .

6. Heating

⭐⭐⭐⭐

Advanced heating is much better in terms of life, heating speed and heat preservation effect than stainless steel heating.

Aluminum heating, ceramic heating and more advanced infrared heating.

Traditional stainless steel heating.

7. Air ring

⭐⭐⭐⭐

The structurally optimized high-speed air ring reduces the wind resistance and make the change of wind volume gentle.

Italian designed high-speed double/ triple vent air ring.

Normal single, double vent air ring from domestic market.

8. Guarantee

⭐⭐⭐⭐

Chaoxin creates a precedent of guarantee period in this industry, which enables clients to get trully hassle-free products & sevice.

Main motor, fan, inverter, die head, gear box are guaranteed for three years.

Other manufacturers basically have a one-year warranty.

9. Production

⭐⭐⭐⭐⭐

5S management standards and high-end machining center equip Chaoxin with precision production capabilities and ensure product standards and quality.

5S management modern standardized workshop.

Traditional and chaotic production management.
